Product no. M-1536

Container 200 liters made of V2A, used, temperature-controllable, isolated, standing

EUR 3.500,00

add. 19 % VAT excl. shipping costs


Volume approx. 200.00 litres



Please note:

A sale is only made to entrepreneurs, traders, freelancers, public institutions and not to consumers i. S.v. § 13 BGB.

  more details

Product description

Container 200 liters made of V2A, used, temperature-controllable, isolated consists of the material 1.4401(AISI316) V4A. The volume is approx. 200.00 litres. The diameter inside includes 600 mm.  Container 200 liters made of V2A, used, temperature-controllable, isolated was last used in the following area: Foodstuffs. Delivery can take place worldwide.

This product is suitable for the following applications:

Storage, Hot water, Boiling, Cooling, Tempering, Mixing, Processes, Anaerobic digestion, Cleaning/CIP, Reactor,

General

  • Volume approx.

  • 200,00 litres

  • Structure

  • Standing

  • Year of manufacture

  • 1984

  • Manufacturer

  • Waldner

  • Condition

  • Used

Dimensions approx.

  • Internal diameter

  • 600 mm

  • External diameter

  • 762 mm

  • Cyl. height

  • 618 mm

  • Total height

  • 2.400 mm

Design

  • Insulation

  • yes

  • Insulated area

  • Shell and floor

  • Insulation cladding

  • Fully welded stainless steel

  • Interior surface

  • Smoothed

  • Exterior surface

  • Smoothed

  • Floor type

  • Torispherical bottom

  • Head design

  • Torispherical bottom

  • Product chamber operating pressure

  • Atmospheric/unpressurised bar

  • Product chamber operating temperature

  • 90 °C

Equipment

  • Temperature-controllable

  • Yes

  • Temperature control area

  • Shell and floor area

  • Temperature control system

  • Half-pipe coils

  • Operating pressure

  • 2 bar

  • Operating temperature

  • 90 °C

Agitator

  • Agitator quantity

  • 1 (piece)

  • Agitator type

  • Propeller

  • Agitator position

  • Head off-centre

  • Agitator 1 - Output

  • 0,4 kW

  • Agitator 1 - RPM

  • 695 UpM

  • Agitator 2 - Output

  • 0,6 kW

  • Agitator 2 - RPM

  • 950 UpM

Supports

  • Supports

  • Stainless steel frame

  • Number of feet

  • 4 (piece)

Fixtures and fittings

  • Handhole 1 size

  • 200 DN mm

  • Handlochposition Handhole position

  • In head

  • Nozzles/connectors in head

  • 1xDN 70 1xDN100 1xDN 25 (piece)

  • Outlet nozzle

  • 50

  • Cleaning/CIP nozzle

  • in head

  • Additional fixtures and fittings

  • Nameplate

Technical documentation

  • Technical documentation

  • None

Other

  • Last usage

  • Foodstuffs

This product is suitable for use as:

Foodstuffs: Foodstuffs tank, Water tank, Wine tank, Mash tank, Fruit juice tank, Spirituous beverages tank, Milk tank, Whey tank, Storage tank, Buffer tank, Pre-buffer tank, Transport tank, Settling tank, Sprinkler tank, Mixing tank, Process tank, Anaerobic digestion tank, CIP tank, Reactor/reaction tank, Boiling tank, Cold water tank,

Agriculture: Substrate tank, Slurry tank, Storage tank, Buffer tank, Pre-buffer tank, Settling tank, Sprinkler tank, Mixing tank, Process tank, CIP tank, Hot water tank, Cooling tank,

Chemistry and pharmaceuticals : Chemical tank, Storage tank, Acid tank, Lye tank, Reactor tank, Buffer tank, Pre-buffer tank, Settling tank, Mixing tank, Process tank, Anaerobic digestion tank, CIP tank, Reactor/reaction tank, Cooling tank, Tempering tank, Cold water tank,
